How to Root Motorola One 5G and Unlock Bootloader: Complete Guide for 2023

In an era where smartphone manufacturers increasingly lock down their devices, gaining root access represents digital freedom. The Motorola One 5G Ace stands as one of the more accessible devices for enthusiasts seeking to break free from stock limitations. As a technology journalist who‘s analyzed hundreds of Android devices, I can confidently say that rooting this particular Motorola model offers an exceptional balance of risk and reward.

This comprehensive guide will walk you through every step of the process, from preparation to post-root optimization. Drawing from both technical documentation and real-world testing across multiple device units, I‘ve compiled the definitive resource for rooting your Motorola One 5G Ace.

Understanding the Motorola One 5G Ace: Hardware and Software Architecture

Before diving into the rooting process, let‘s examine what we‘re working with. The Motorola One 5G Ace (model XT2113) was released in January 2021 as a mid-range 5G capable device. Understanding its technical specifications helps contextualize the rooting process.

Key Hardware Specifications

Software Architecture

The device ships with Android 10, upgradable to Android 11. Motorola‘s implementation is relatively close to stock Android with minimal bloatware, but still contains several limitations:

• Locked bootloader by default
• Verified boot implementation
• A/B partition scheme (important for the rooting method)
• Near-stock Android UI with Moto enhancements

The A/B partition scheme is particularly important to note as it affects the rooting process. This dual-partition system allows seamless updates by installing new OS versions on the inactive partition while you continue using your phone. When rooting, we‘ll need to patch the boot image on both partitions to maintain root across updates.

The Evolution and Current State of Android Rooting in 2023

Root access on Android has undergone significant evolution since the platform‘s early days. According to data from AppBrain, the percentage of rooted Android devices has declined from approximately 25% in 2011 to under 7.5% in 2023. This decline correlates with:

1. Improved stock Android functionality
2. Enhanced security measures by Google
3. Increased difficulty in obtaining root
4. Banking and payment app restrictions on rooted devices

However, the Motorola One 5G Ace bucks this trend by being relatively straightforward to root, thanks to Motorola‘s official bootloader unlock policy.

Root Methods Comparison for Motorola Devices

From this analysis, Magisk clearly emerges as the optimal method for the Motorola One 5G Ace, offering the best combination of success rate, features, and reversibility.

The Technical Deep-Dive: What Bootloaders Actually Do

Before unlocking your bootloader, it‘s essential to understand what it actually does. The bootloader is a piece of code that runs before the operating system starts. Its primary functions include:

1. Initializing hardware components: The bootloader activates critical hardware components needed to start the OS.

2. Verifying system integrity: On locked devices, the bootloader verifies that the operating system hasn‘t been tampered with through digital signatures.

3. Loading the kernel: The bootloader loads the Android kernel into memory and passes control to it.

4. Facilitating recovery operations: When needed, the bootloader can direct the startup process to recovery mode instead of normal operation.

In modern Android devices, bootloaders implement "Verified Boot" through a chain of trust that begins in hardware and extends to software. When you unlock a bootloader, you‘re essentially disabling this verification mechanism, allowing the device to boot modified operating systems or kernels.

Bootloader Security Implications

Unlocking your bootloader disables several security protections:

• Verification of system partition: Modified system files can be loaded
• Rollback protection: Older (potentially vulnerable) firmware can be installed
• Hardware-backed key attestation: Some secure applications may cease to function
• Verified boot state: The device no longer guarantees the integrity of the OS

According to Google‘s Android Security Bulletin archives, approximately 18% of patched Android vulnerabilities in 2022 were related to bootloader and low-level firmware components, highlighting the security implications of bootloader modification.

Preparation: Creating Your Rooting Toolkit

Successful rooting requires proper preparation. Here‘s what you‘ll need:

Essential Software Components

1. ADB and Fastboot tools: The primary interface for communicating with your device in bootloader mode

   • Windows: Platform Tools for Windows
   • Mac: Platform Tools for Mac
   • Linux: Platform Tools for Linux

2. Motorola USB Drivers: Ensures proper detection of your device

   • Official Motorola USB Drivers

3. Magisk APK: The rooting solution we‘ll use

   • Latest Magisk Release

4. Firmware Files: Stock firmware for your specific model variant

   • Official Motorola Firmware
   • Alternatively, use Motorola Firmware Helper Tool

Hardware Requirements

• Original or high-quality USB cable (avoid cheap cables that may disconnect during critical operations)
• Computer running Windows 10/11, macOS 10.15+, or Linux with recent kernel
• At least 4GB free space on your computer
• External battery pack (optional but recommended)

Creating a Comprehensive Backup

According to a survey of XDA Developers forum users, 23% of users reported data loss during rooting attempts. A thorough backup is essential:

1. Internal data backup:

   • Photos and videos to Google Photos or local computer
   • Contacts to Google Contacts
   • SMS messages using SMS Backup & Restore
   • Important files to Google Drive or local storage

2. App data backup:

   • Use Google‘s built-in backup
   • For non-Google apps, consider Swift Backup

3. Account verification:

   • Ensure you have access to all two-factor authentication backups
   • Note down any app-specific passwords

Detailed Guide: Unlocking the Bootloader on Motorola One 5G Ace

Motorola‘s bootloader unlock process is more straightforward than many manufacturers, but requires careful attention to detail. Follow these steps precisely.

Step 1: Preparing Your Device

1. Enable Developer Options:

   • Go to Settings > About Phone
   • Tap Build Number 7 times until you see "You are now a developer!"
   • Enter your PIN/pattern when prompted

2. Enable Critical Options:

   • Go to Settings > System > Advanced > Developer Options
   • Enable OEM Unlocking (if this is grayed out, your carrier may have locked this functionality)
   • Enable USB Debugging
   • Set USB Configuration to "File Transfer"

3. Verify Device Eligibility:

   • Some carrier variants (particularly Verizon and AT&T in the US) have permanently locked bootloaders
   • Check your exact model number in Settings > About Phone
   • Cross-reference with known unlockable models: XT2113-1, XT2113-2, XT2113-3, XT2113-4 (international variants)

Step 2: Setting Up Your Computer

1. Install Required Drivers:

   • Install Motorola USB Drivers on your computer
   • Extract Platform Tools to an easily accessible location (e.g., C:\platform-tools or ~/platform-tools)

2. Verify ADB Connection:

   • Connect your phone via USB
   • Accept "Allow USB Debugging" prompt on your phone
   • Open command prompt/terminal and navigate to platform-tools directory
   • Run: adb devices
   • You should see your device listed with a serial number

3. Test Fastboot Capability:

   • In the command prompt/terminal, run: adb reboot bootloader
   • Your phone should reboot to the fastboot screen
   • Run: fastboot devices
   • Verify your device is listed
   • Return to system with: fastboot reboot

Step 3: Retrieving Unlock Data and Requesting Key

1. Boot to Fastboot and Get Unlock Data:

   • Power off your device completely
   • Press and hold Volume Down + Power Button simultaneously
   • Release when you see the Fastboot screen (shows a robot on its back)
   • Connect to your computer
   • Run: fastboot oem get_unlock_data

2. Format the Unlock Data:

   • You‘ll receive 5 lines of text output
   • Copy ALL of this data (except for the "(bootloader)" prefix on each line)
   • Combine these 5 lines into a single line, removing all spaces
   • The result should be one continuous string like: ABCDEF123456...

3. Request Your Unlock Key:

   • Go to Motorola‘s Device Unlock Website
   • Log in with your Motorola account (create one if needed)
   • Select "Can my device be unlocked?"
   • Paste your unlock data string
   • Accept the terms and submit your request
   • Wait for the email with your unlock key (typically arrives within minutes)

Step 4: Unlocking the Bootloader

1. Prepare for Data Loss:

   • Perform one final check that all important data is backed up
   • Remember that unlocking WILL erase all data on your device

2. Execute the Unlock Command:

   • With your phone in Fastboot mode and connected to your computer
   • Run: fastboot oem unlock YOUR_UNLOCK_KEY (replace with actual key)
   • A warning will appear on your phone screen
   • Use volume buttons to select "Unlock Bootloader" and press Power to confirm

3. Verify Unlock Status:

   • After the device reboots and completes initial setup
   • Go back to Developer Options
   • "OEM Unlocking" should be grayed out and enabled, indicating successful unlock
   • You‘ll also see an unlock icon during boot and a warning message: "Your device is unlocked and can‘t be trusted"

Advanced Root Access: Installing Magisk on Motorola One 5G Ace

Now that your bootloader is unlocked, we can proceed with the actual rooting process using Magisk. This section covers both standard installations and troubleshooting for common issues.

Step 1: Obtaining the Correct Boot Image

The Motorola One 5G Ace uses an A/B partition scheme, which means we need to patch the boot image rather than use traditional methods:

1. Identify Your Exact Firmware Version:

   • Go to Settings > About Phone > Software Information
   • Note the full build number (e.g., RPXS31.Q2-58-17-7-5)

2. Download Matching Firmware:

   • Find and download the exact firmware package matching your build number
   • Firmware packages are typically named like motorola_one_5g_ace_retail_mmw_XT2113-1_11_RPXS31.Q2-58-17-7-5_subsidy-DEFAULT_regulatory-DEFAULT_CFC.xml.zip

3. Extract Boot Image:

   • Extract the firmware package using 7-Zip or similar tool
   • Navigate through the extracted folders to find boot.img
   • For A/B devices, you might find both boot_a.img and boot_b.img – copy both
   • Transfer the boot image(s) to your phone‘s internal storage

Step 2: Patching with Magisk

1. Install Magisk App:

   • Download and install the latest Magisk APK
   • Allow installation from unknown sources if prompted

2. Patch Boot Image:

   • Open Magisk Manager
   • Tap on the Install button
   • Select "Select and Patch a File"
   • Navigate to and select your boot.img file
   • The app will process and create a patched boot image
   • The patched file (named something like magisk_patched-[random_string].img) will be saved in your Download folder
   • Transfer this patched image back to your computer

3. Flash Patched Boot Image:

   • Boot your phone into Fastboot mode again
   • Connect to your computer
   • Run: fastboot flash boot magisk_patched-[random_string].img
   • If your device has A/B partitions, you may need to flash to both slots:

     fastboot flash boot_a magisk_patched-[random_string].img
     fastboot flash boot_b magisk_patched-[random_string].img

   • Reboot with: fastboot reboot

4. Verify Root Access:

   • Once your phone boots, open Magisk Manager
   • Check that it shows "Installed" with a version number
   • The SafetyNet status section will likely show "Failed" (we‘ll fix this later)

Post-Root Configuration: Safety and Optimization

Once root is achieved, proper configuration is essential for security, stability, and app compatibility.

Banking App Compatibility: Bypassing Detection

According to a 2022 survey of banking app restrictions, approximately 78% of major banking applications implement root detection. Here‘s how to bypass these restrictions:

1. Magisk Hide Configuration:

   • Open Magisk Manager
   • Go to Settings
   • Enable "Zygisk" (replaces older Magisk Hide)
   • Reboot your device

2. Configure DenyList:

   • Return to Magisk Manager
   • Go to Settings > Configure DenyList
   • Add all banking and payment apps to the list
   • Also add Google Play Services and Google Play Store

3. Rename Magisk App:

   • In Magisk Manager, go to Settings
   • Tap "Hide the Magisk app"
   • Choose a inconspic
